1.5mm LED Display Solutions From Dynamo LED Displays
Our 1.5mm LED Display Solutions
Dynamo have launched their latest 1.5mm LED display solutions, perfect for those looking for the best LED display solutions. There are two versions of LED cabinet with one (DRE Series) designed to be compatible with both Bematrix and Aluvision frameworks as well as other 55mm/62mm frame building solutions.
and a second (DRA Series) that is designed to be easily installed directly to walls for more permanent installations.
Both cabinets utilise our X-Res LED module technology which features a resin covering over the LEDs, making it impact proof, moisture proof, dust proof and UV proof.
X-Res Spec
Our X-Res spec features a resin glue protection on the LEDs, providing true black and high contrast. The resin coating diffuses heat, making it more efficient and lengthening the life span of the hardware. The surface is also smooth and black, with no visible pixels when up close.
High Refresh Rate
Our 1.5mm LED display solutions feature a high refresh rate, making it perfect for XR Studios and permanent installations in a variety of scenarios. The surface can also be cleaned unlike SMD which can’t because the surface mounted diode cannot be exposed to any moisture.
Multi-Purpose Solution
Our 1.5mm LED display solutions are multi-purpose and can be used on walls and floors. The solution can create XR Studios and can also be used in permanent installations in a variety of scenarios. The solution is also dust proof, moisture proof, UV proof and impact proof, making it perfect for any environment.
Specification
| PITCH | P1.55 |
|---|---|
| Series | DRE155I |
| SMD mode (cd/m²) | >800 |
| DISTANCE | >1.55M |
| LED kind | MicroX |
| PROTECTION | X-GOB |
| TECHNOLOGY | MicroX |
| REFRESH RATE | 1920Hz-3840Hz |
| Viewing Angle | 160°(H) | 160°-(V) |
| CONTRAST | 6000:1 |
| MODULE SIZE | 248 x 248 mm 496 x 496 x 55 mm / 62 mm |
| CABINET SIZE | 19.5″ x 19.5″ x 2.2″ / 2.4″ |
| CABINET RES (px) | 320 x 320 |
| SYSTEM | Stacking / Hanging / Stitching |
| DRIVE MODE (Scan) | 1/32 |
| ENVIRONMENT | IP40 / IP20 |
| MAX POWER (w/m²) | (CCT) 600W/m² |
| VOLTAGE | AC 100-240V |
| WEIGHT | 9.2kg/Panel (No extensions) |
| CERTIFICATION |
CE, EMC,TUV-EMMC,FCC, ETL, UL,PSE, CCC, RoHS
|
