LED FLOOR SYSTEM
The DEX series products are full-colour LED floor tiles that are easy to maintain, portable, flexible, and easy to install. As a result of our unique X-Res technology โ which avoids color shifting โ our LEDs are especially suitable for use on floors or in XR exhibits. Brompton, one of our partners, supports the DEX series.
COMPLETE FRONT MAINTENANCE
Due to the magnetic structure, it can be easily accessed from the front, reducing maintenance time and effort. Power pack which contains the power supply and receiver cards can be completely removed from the front.
FRAME SYSTEM
DRE and DEX cabinets fix to the same 55mm and 62mm frame systems; pictured: DRE. The cabinets fix directly to modular frames such as Aluvision and beMatrix, with M6 fixings for the 55mm system and M8 fixings for the 62mm system. Cabinets can be stacked, hung or turned through a 90 degree corner. See our Aluvision frames and compatible LED tiles page for more on LED in a frame-built stand.
Specification
| PITCH | P2.0 |
|---|---|
| Series | DEX206i |
| True Black SMD | >1000cd/mยฒ |
| Distance | >2m |
| LED kind | SMD1010 |
| Pixel Density | 250000 dots/mยฒ |
| Technology | MicroX |
| Refesh rate | 1920Hz – 3840Hz |
| Viewing Angle | 160โฐ(H)/160โฐ(V) |
| Contrast | 6000:1 |
| Mac.Stacking | 20 Cabinets |
| Module Size | 248x248mm |
| Cabinet Size | 496x496mm(19.5”x19.5”x2.1”) |
| System | Stacking,Hanging,Stitching |
| Cabinet Res. | 248x248px |
| Drive Mode | IP20 |
| Environment | IP65/IP54 |
| Max Powe | 420W/mยฒ |
| Voltage | AC 100-240V |
| Weight | 7.5kg/Panel |
| Certification | CE, EMC, TUV-EMC, FCC, ETL, UL, PSE, CCC, ROHS |
