Novastar NovaPro UHD All in one Controller

£8,995.00

SKU NovaPro-UHD Category Tags , , , , ,

Overview

The NovaPro UHD is a new all-in-one controller developed by NovaStar. Featuring video processing and control, and the built-in Master VI platform software, the NovaPro UHD allows you to easily manage layers and configure screens by using a mouse, keyboard and monitor. The NovaPro UHD is capable of receiving a variety of video signals and processing images of resolutions up to Ultra HD 4K×2K@60Hz and 8K×1K@60Hz. It comes with a maximum loading capacity of 10,400,000 pixels and can send the processed videos to LED displays using Neutrik Ethernet ports and fiber optical ports.

Thanks to the powerful video processing and sending capabilities, the NovaPro UHD is widely used for high-end rental applications, stage control systems and fine-pitch fixed LED displays.

Features

  • Industry-standard input connectors
    – 4x 12G-SDI (IN-LOOP)
    – 1x HDMI 2.0 (IN-LOOP)
    – 1x DP 1.2
    – 4x HDMI 1.3 (Purchase a DVI input card to
    replace the connectors.)
  • 16x Neutrik Ethernet outputs and 4x OPT outputs connectors
    – Two modes available on fiber optical output ports: copy and hot backup
    − The maximum loading capacity is 10,400,000 pixels. The maximum output width and height per unit reach up to 16,384 pixels 8192 pixels respectively.
  • 6x layers
    – Up to 2x 4K×2K and 4x 2K×1K layers can be added, and layer scaling is available.
    − Flexible layer adjustment, including opacity, mask, overlapping, copying, mirroring, flipping, etc.
    − Irregular layer supported
    − Z-order sorting
  • 1x OSD, 1x LOGO and 1x BKG
    – OSD supports cropping, opacity adjustment, dynamic and static images, and position settings.
    – LOGO supports resolutions up to 256×256 and allows for cropping, opacity adjustment and position settings
    − BKG can be scaled to fit the screen automatically.

  • Built-in Master VI platform software allowing for
    easier operations
  • Working with the A8s or A10s Plus receiving card to support HDR function, making images smoother
  • Low latency output
    The end-to-end delay can be as low as 1 frame when the low latency and synchronization functions are turned on and the data runs vertically on the screen.
  • Multiviewer settings
    Monitor the input sources, PVW or PGM, or perform mixed monitoring.
  • Web control
    Access and control the NovaPro UHD in real time by using a browser without the need to install multiple pieces of software.
  • Up to four NovaPro UHD units can be linked together for image mosaic.
  • Decimal frame rates supported
    The supported frame rates are 23.98 Hz, 29.97 Hz, 47.95 Hz, 59.94 Hz, 71.93 Hz, 119.88Hz and 143.86Hz.
  • Genlock synchronization, fit for XR application scenarios
  • PGM editing supported

Appearance

Front Pane

NovaPro-HD-front-panel
Button Function
On/OFF button
Hold down the button for 3 seconds to power on, power off or restart the device.
Layer buttons

Open or close layers and display layer status.
Status LEDs:

  •  On (blue): The layer is open and an input source is accessed.
  • Flashing (blue): The layer is being edited and an input source is accessed.
  • On (white): The layer is open, but no input source is accessed.
  • Flashing (white): The layer is being edited, but no input source is accessed or the input
    source is abnormal.
  • Off: The layer is closed.
Input source buttons

Quickly switch the layer input source and display the input source status.
Press an input source button to switch to the input source.
Status LEDs:

  • On (blue): The input source is accessed and being used by a layer.
  • On (white): The input source is accessed but not in use.
  • Off:
    − The input source is not accessed or abnormal.
    – The input source is not accessed but already used by a layer
TFT screen
Display current device status, menus, submenus and messages.
Knob
  • Rotate the knob to scroll through the menu items, or adjust a parameter value.
  • Press the knob to confirm the selection or settings.
Function buttons
  •  Enter or exit the quick navigation screen.
  •  Make the LED screen fade to black.
  • Access the LOGO menu.
  • Access the preset menu.
  • Freeze the output image.
  • Access the OSD menu.
  • Custom function button
  • Access the test pattern menu.
  • Access the BKG settings menu.
  • Send the PVW to PGM with a transition effect.
  • Send the PVW directly to PGM without a transition effect.
ESC button
Exit the current menu or cancel an operation
USB ports

2x USB2.0

  • Connect to a mouse and keyboard to control the device with the built-in GUI.
  • Insert a USB drive to update the system.
  • Insert a USB drive to import or export files.

Rear Panel

NovaPro-HD-rear-panel

Input

Connector Quantity Description
12G-SDI
4
  • Supports ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G) and ST-292 (HD).
  • Up to 4K×2K@60Hz input resolution
  • Connector 4 supports deinterlacing processing.
  • Supports 12G-SDI output with loop-through

Note:
When the input source is a 12G-SDI signal, a CANARE / L-4.5CHD+ /
UHDTV-SDI SDI cable is required and it cannot be longer than 50 m.
DP 1.2
1
  • Up to 4K×2K@60Hz (8K×1K@60Hz) input resolution
  • HDCP 1.3 compliant
  • Does not support interlaced input signals.
HDMI 2.0
1
  •  Up to 4K×2K@60Hz (8K×1K@60Hz) input resolution
  • HDCP 1.4 and HDCP 2.2 compliant
  • Does not support interlaced input signals.
  • Supports HDMI 2.0 output with loop-through.
HDMI 1.3
4
  • D_4×HDMI 1.3 input card (can be replaced by a D_4×DVI input card)
  • Up to 1920×1080@60Hz input resolution for each connector
  • HDCP 1.3 compliant
  • Supports interlaced input signals.

Output

Connector Quantity Description
Ethernet port
16

Neutrik Gigabit Ethernet outputs

  • Max. loading capacity: 10.4 million pixels
  • Max. width: 16,384 pixels
  • Max. height: 8,192 pixels
OPT 1–4
4

10G fiber optical outputs (copy and hot backup)

  • OPT 1 transmits data on Ethernet ports 1–8.
  • OPT 2 transmits data on Ethernet ports 9–16.
  • OPT 3 is the copy/hot backup channel for OPT 1 input signals.
  • OPT 4 is the copy/hot backup channel for OPT 2.
MVR
1
  • HDMI 1.3 connector, used for Multiviewer to monitor input sources, PVM or
    PGM, or perform mixed monitoring
AUX
1
HDMI 1.3 connector, used for connecting to an auxiliary device such as a teleprompte

Control

Connector Quantity Description
ETHERNET
1

For PC communication or network connection
USB
3
  • 1x USB 2.0 (Type-B): Connect to the PC for device debugging
  •  2x USB 2.0 (Type-A):
    Insert a USB drive to update the system.
    – Connect to a mouse and keyboard.
    – Output port for linking another device unit
GENLOCK IN-LOOP
1

Connect to a synchronization signal source

  •  IN: Accept the sync source
  • LOOP: Loop the sync source
CONTROL UI
1
Connect to a monitor for displaying the user interface of the Master VI platform software.
Specifications
Electrical Specifications
Power connectors
100–240V~, 50/60Hz, 7.2A–3.5A Dual redundant power supplies
Rated power consumption
180 W
Operating Environment
Operating temperature
–10°C to +60°C
Humidity
0% to 80%, non-condensing
Storage Environment
Storage humidity
0% to 95%, non-condensing
Physical Specifications
Dimensions
482.6 mm × 183.9 mm × 497.5 mm
Net weight
21 kg
Gross weight
42 kg
Packing Information
Accessories
  • 2x Power cords
  • 1x DVI cable
  • 1x USB cable
  • 1x Ethernet cable
  • 1x HDMI cable
  • 1x DP cable
  • 1x Mini DP to DP cable
  • 46x Silicone dustproof plugs
  • 1x USB drive (16 GB)
  • 1x Custom Letter
  • 1x Quick Start Guide
  • 1x Certificate of Approval
  • 1x Safety Manual
Flight case

531 mm × 286 mm × 786 mm
Certifications

FCC, IC, UL/CUL, CB, CE, RoHS 10, EAC, RCM, PSE
Note:
If the product does not have the relevant certifications
required by the countries or regions where it is to be
sold, please apply for the certifications yourself or
contact NovaStar to apply for them.
Noise Level (typical at 25°C/77°F)
57 dB (A)

Applications

Appearance-NovaPro-HD

Dimensions

NovaPro-HD-dimensions
Specifications
Electrical Specifications
Power connectors
100–240V~, 50/60Hz, 7.2A–3.5A Dual redundant power supplies
Rated power consumption
180 W
Operating Environment
Operating temperature
–10°C to +60°C
Humidity
0% to 80%, non-condensing
Storage Environment
Storage humidity
0% to 95%, non-condensing
Physical Specifications
Dimensions
482.6 mm × 183.9 mm × 497.5 mm
Net weight
21 kg
Gross weight
42 kg
Packing Information
Accessories
  • 2x Power cords
  • 1x DVI cable
  • 1x USB cable
  • 1x Ethernet cable
  • 1x HDMI cable
  • 1x DP cable
  • 1x Mini DP to DP cable
  • 46x Silicone dustproof plugs
  • 1x USB drive (16 GB)
  • 1x Custom Letter
  • 1x Quick Start Guide
  • 1x Certificate of Approval
  • 1x Safety Manual
Flight case

531 mm × 286 mm × 786 mm
Certifications

FCC, IC, UL/CUL, CB, CE, RoHS 10, EAC, RCM, PSE
Note:
If the product does not have the relevant certifications
required by the countries or regions where it is to be
sold, please apply for the certifications yourself or
contact NovaStar to apply for them.
Noise Level (typical at 25°C/77°F)
57 dB (A)

Video Source Features

Input Connector B Bit Depth Max. Input Resolution
  • HDMI 2.0
  • DP 1.2
8-bit
RGB 4:4:4

4096×2160@60Hz
8192×1080@60Hz
YCbCr 4:4:4
YCbCr 4:2:2
YCbCr 4:2:0
Not supported
10-bit

RGB 4:4:4

YCbCr 4:4:4

YCbCr 4:2:2
YCbCr 4:2:0

4096×2160@30Hz
8192×1080@30Hz

4096×2160@60Hz
8192×1080@60Hz

Not supported
12-bit

RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2
YCbCr 4:2:0

4096×2160@30Hz
8192×1080@30H
4096×2160@60Hz
8192×1080@60Hz
Not supported
HDMI 1.3

8-bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2

10-bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2

12-bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2




1920×1080@60Hz
12G-SDI
  • Max. input resolution: 4096×2160@60Hz
  • Does not support input resolution and bit depth settings.
  • Supports ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G) and ST-292 (HD).
