DBS-HVT11out full color LED sender Box
Get ready for an amazing LED display experience with the DBS-HVT11out Full Color LED Sender Box! This sending box offers a variety of features that make managing your LED display simpler than ever. The HVT11out provides smooth streaming capabilities, vivid full color visuals and reliable control options all in one convenient device. With this sending box, you can create stunning visuals that will captivate viewers and leave them wanting more. Take full control of your LED displays with the DBS-HVT11out Full Color LED Sender Box!
|
ย Type
|
Typical value
|
Max value
|
|
ย Supported screen type
|
ย single color, dual-color,full-color, real pixel,virtual pixel.
|
|
|
ย Supported LED drivers
|
MBI5026/MBI5030/MBI5036/
MBI5039/MBI5042/MBI5050/MBI6024/ LPD6803/DM413/DMX512/ZQL9726
TCD62D722/TC62D766/MBI5050/MBI6024
|
|
|
ย Pixels by single sending card
|
2048ร640(dual ports)
|
|
|
ย Number of receiving cards connected by cable
|
<100
|
256
|
|
ย Pixels by single receiving cards
|
256 x192 full colorรฏ
1024 x512 dual color
|
512ร384 full color
1280 x512 dual color
|
|
ย RGB data groups by single receiving card
|
16-24
|
24
|
|
ย Lines by one group RGB
|
1/2/4/8/16/32
|
32
|
|
Grey grades
|
4096(4k)
|
65536(64k)
|
|
ย Data CLK frequency
|
15.62MHz
|
31.25MHz
|
|
ย Refresh rate
|
180Hz
|
>3600Hz(รฅยฆโMBI5042)
|
|
ย Brightness wastage
|
15~20%
|
<5%
|
|
ย PWM brightness adjust degree
|
256(may automatically adjust by brightness sensor)
|
|
|
Electronic current plus brightness adjustment grade
|
64/256(according to led drivers)
|
|
|
ย Dot by dot revise pixels by PWM brightness
|
64ร64
|
256ร256
|
|
Pixels on open circuit and short circuit error detection
|
staticรฏยผลก2048ร16รฏยผโบ1/2รฏยผลก1024ร16รฏยผโบ
1/4รฏยผลก2048ร16รฏยผโบ1/8รฏยผลก4096ร16รฏยผโบ1/16รฏยผลก8192ร16 |
|
|
ย Fiber transmission distance
|
ย Multi-mode fiber รฏยผลก500metersรฏยผโบ single-mode fiberรฏยผลก10KMs
|
|
|
ย Other functions
|
ย Power on gradual protection รฃโฌยOE Polarity switch protect screen scan tubes, led screen self-detecting
|
|
|
No sending card function
|
Sending images by 1000M network card PC
|
|
